4-1
4. INSTALLATION
4.1 Equipment List
Standard supply
Optional supply
*: See the Packing lists.
4.2 Installation of Remote Display
Mounting considerations
The remote display can be installed on a desktop, on the underside of a table, or flush
mounted in a panel. When you select a mounting location, keep in mind the following
points:
• The nominal viewing distance for the remote display is 1 m. Select a suitable mount-
ing location considering that distance.
• Locate the remote display away from exhaust pipes and vents.
• Select an installation location that is well ventilated.
• Locate the remote display where shock and vibration are minimal.
• Locate the remote display away from equipment which generates the electromag-
netic fields like a motor or generator.
• Allow enough maintenance space at the sides and rear of the remote display and
leave enough slack in cables to facilitate maintenance and servicing.
• Observe the compass safe distances (see page ii) to prevent the interference to a
magnetic compass.
Name Type Code No. Qty Remarks
Remote Display RD-50 - 1
Installation Materials CP26-01501* - 1
Accessories FP26-00601* - 1
Spare Parts SP26-00101 001-076-380-00 1 Fuse (2 pcs.,
FGMB 125V 2A PBF,
000-157-479-10)
Name Type Code No. Remarks
Remote Controller RD-501 - CP26-01101*
Dimmer Controller RD-502 - CP26-01201*
Hanger OP26-8 000-016-313-00
Waterproof Box DS-605 000-016-398-00
To Next Page
