4. INSTALLATION
4-5
4.4 Installation of Remote Display with DS-605
(Waterproof Box)
For installation of the remote display on the wings of the bridge, use the optional wa-
terproof box DS-605. Fix the DS-605 on the bulkhead and set the remote display
therein.
Installation materials for DS-605 (Type: CP66-01731, Code No.: 001-082-660-00)
*: Not for the RD-50 but for the DS-60.
Mounting considerations
The DS-605 has waterproofing protection of IP56. When you select a mounting loca-
tion for the waterproof box, keep in mind the following points.
• Keep the unit away from electromagnetic field-generating equipment like motors
and generators.
• For maintenance and checking purposes, leave enough space at the sides of the
unit and leave slack in cables. Refer to page D-5.
• A magnetic compass will be affected if the waterproof box is too close to the mag-
netic compass. Observe the compass safe distances (see page ii) to prevent inter-
ference to a magnetic compass.
Mounting procedure
Note: Mount the DS-605 on the bulkhead so the cable glands and the drain hole are
down.
1. Fix the DS-605 on the wings of the bridge.
1) Insert the seal washer to four fixing holes.
Name Type Code No. Qty
Seal washer 03-001-3002-0 ROHS 300-130-020-10 4
Gasket 26-003-1605 100-355-310-10 1
Washer 26-003-1607 100-355-320-10 2
Cable gland washer* For JIS F8801 25C 000-172-238-10 2
Cable gland inner gasket* For JIS F8801 25C 000-171-892-10 1
Silicon rubber
S-8400W
Aluminum tube 50G
000-158-483-10 1
