APPENDIX 1 MENU TREE
MENU key
Source
Summer Time (ON, OFF)
Internal
External
DISP1 - DISP5 ( , , , , , , , )*
Unit (DISP1 - DISP5)
Mode (DISP1 - DISP5)
Speed Graphic
(DISP1 - DISP5)
Depth Graph (DISP1 - DISP5)
Water TEMP Graph
(DISP1 - DISP5)
Rudder (DISP1 - DISP5)
Engine/Shaft (DISP1 - DISP5)
Digital on Graphic (ON, OFF)
Rudder Order Symbol (ON, OFF)
Direction Symbol (Arrows, Text)
Symbol Location (Left, Right)
Wind Average (No Averaging, 1min, 2min, 3min, 5min, 10min)
BRILL
Speed Select (Forward-After, Vector)
TESTS (Self TEST, LCD TEST)
User RESET (Yes, No)
Ship’ s
Time
Trip
DIST
Display
Scale
Set Up
System
Internal (-13:00 - +13:00)
External
NAV EQUIP
RESET
SET (000000.0NM - 999999.9NM)
Speed (kn, m/s, km/h)
Distance (NM, km)
Depth (m, ft, fm)
Wind Speed (kn, m/s, km/h, mph)
Water TEMP (
°
C,
°
F)
Time (UTC, Ship’ s Time)
Speed (Auto, SOG, STW, GPS)
HDG/COG (True, Magnetic)
Wind (True, Theoretical 360
°
/180
°
, Relative 360
°
/180
°
)
Astern SPD Scale (5kn (2.5m/s, 10km/h))
Ahead SPD Scale (25kn (12.5m/s, 50km/h))
Range (Auto, User Setting)
Period (5min, 15min, 30min, 1hr, 3hr, 6hr, 12hr, 24hr)
Painted Graph (ON, OFF)
Graph Clear (Yes, No)
Range (5
°
C (10
°
F), 10
°
C (20
°
F), 20
°
C (40
°
F))
Period (5min, 15min, 30min, 1hr, 3hr, 6hr, 12hr, 24hr)
Painted Graph (ON, OFF)
Graph Clear (Yes, No)
Graphic Range (40deg - 180deg)
Position (Single, Port, Starboard)
(100RPM, 150RPM, 200RPM, 250RPM, 300RPM,
400RPM, 500RPM, 750RPM, 1000RPM)
Key BRILL (1 - 8, 2)
BRILL OFFSET (-3 - +3, 0)
*: See APPENDIX 2.
Bold: Default setting
