FUTABA T6K-V2 User Manual

118
Airplane
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe+
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
1AIL 2AIL1AIL1FLP 2AIL1FLP ELEVONWINGTYPE
This mixing is used with delta wing, tail-less, and
disk shaped airplanes that combine the aileron and
elevator functions.
Connect the CH1 servo to the left aileron and the
CH2 servo to the right aileron.
ŏ7KHDLOHURQDQGHOHYDWRUWUDYHOFDQEHDGMXVWHG
LQGLYLGXDOO\
"ELEVON"
ELEVON
Elevon
(AIRPLANE)
Aileron1（CH1）rate
Aileron2（CH2）rate
Elevator2（CH1）rate
Elevator1（CH2）rate
（Aileronrate）
L：AileronstickLeftsiderate
R：AileronstickRightsiderate
（Elevatorrate）
● Selectthesettingitemwith
theJogkey.
■Activatingthefunction
①Selectthe"ELEVON"byWING
type(MDLTYP).
■ Rateset
＋ −
or
②Selectthe"RATE"itemandthenadjust
themixingratebypressingthe+keyor
‒key.
Range：-120to+120%
Default：+100%
（onlyELE1:-100%）
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
NOTE：Werecommendthatsettingbeperformedwhilemovingthestickandcheckingtheamountof
movement.Iftheamountofmovementistoolarge,elevatorandaileronoperationwillbecompoundedandthe
servotravelrangewillbeexceededandadeadbandinwhichtheservowillnotoperatemaybecreated.
ELEVON
CH1
CH1
CH2
CH2
Pitch(Elevatoroperation)
Roll(Aileronoperation)
SelecttheLeft/
Rightwiththe
aileronstick.
