FUTABA T6K-V2 User Manual

Beforeuse
43
Rubber
grommet
Brass eyelet
Wood screw
Servo mount
2.3-2.6mm nut
washer
Rubber
grommet
Brass eyelet
Servo mount
2.3-2.6mm screw
(Helicopter) (Airplane/Glider)
6HUYROHDGZLUHV
To prevent the servo lead cable from being
EURNHQE\YLEUDWLRQGXULQJIOLJKWSURYLGHD
little slack in the cable and fasten it at suitable
SRLQWV3HULRGLFDOO\FKHFNWKHFDEOHGXULQJGDLO\
maintenance.
Fasten about 5-10cm
from the servo outlet so
that the lead wire is neat.
Slack in the lead wire.
ŰŲŸűŷŬűŪŃŷūŨŃųŲźŨŵŃ
ŶźŬŷŦūŃ
:KHQPRXQWLQJDSRZHUVZLWFKWRDQDLUIUDPH
make a rectangular hole that is a little larger than
the total stroke of the switch so that you can turn
WKHVZLWFK212))ZLWKRXWELQGLQJ
Avoid mounting the switch where it can be
FRYHUHGE\HQJLQHRLODQGGXVW,QJHQHUDOLWLV
recommended to mount the power switch on the
VLGHRIWKHIXVHODJHWKDWLVRSSRVLWHWKHPXIÀHU
ŶŤũŨŷżŃųŵŨŦŤŸŷŬŲűŶŃ
ƚƋƈƑŃƜƒƘŃƌƑƖƗƄƏƏŃƕƈƆƈƌƙƈƕŃ
ƄƑƇŃƖƈƕƙƒƖ
WARNING
&RQQHFWLQJFRQQHFWRUV
Be sure to insert the connector until it stops
at the deepest point.
+RZWRSURWHFWWKHUHFHLYHUIURP
YLEUDWLRQDQGZDWHU
Wrap the receiver with something soft such
as foam rubber to avoid vibration. If there is
a chance of getting wet, put the receiver in
a waterproof bag or balloon to avoid water.
5HFHLYHUVDQWHQQD
Never cut the receiver's antenna. Do not
bind the receiver's antenna with the cables
for servos.
Locate the receiver's antenna as far as pos-
sible from metals or carbon fiber compo-
nents such as frames, cables, etc.
*Cutting or binding the receiver's antenna will
UHGXFHWKHUDGLRUHFHSWLRQVHQVLWLYLW\DQGUDQJH
and may cause a crash.
Install in a way that makes sure that the 2
antennas won’t touch the ground.
6HUYRWKURZ
Adjust your system so that pushrods will not
bind or sag when operating the servos to
the full extent.
,IH[FHVVLYHIRUFHLVFRQWLQXRXVO\DSSOLHGWRD
VHUYRWKHVHUYRFRXOGEHGDPDJHGGXHWRIRUFH
on the gear train and/or power consumption
causing rapid battery drain.
0RXQWLQJVHUYRV
Use a vibration-proof rubber (such as rub-
ber grommet) under a servo when mounting
the servo on a servo mount. And be sure
that the servo cases do not touch directly to
the metal parts such as servo mount.
,IWKHVHUYRFDVHFRQWDFWVWKHDLUIUDPHGLUHFWO\
vibration will travel to and possibly damage the
servo.
ŰŲŸűŷŬűŪŃŷūŨŃŶŨŵŹŲŃ

FUTABA T6K-V2 Specifications

General

Brand	FUTABA
Model	T6K-V2
Category	Remote Control
Language	English
