Beforeuse
20
The charging time when charging the HT5F1800B battery
with the optional special charger is approximately 15 hours.
+RZHYHUZKHQWKHEDWWHU\KDVQRWEHHQXVHGIRUVRPHWLPH
repeat charging 2 or 3 times to activate the battery.
AC outlet
Charger
Transmitter
charging LED
To transmitter
charging jack
To receiver
NiCd battery
Cannot be used for
charge of LiFe.
Balance charging connector for
LiFe battery charger.
Charging A LiFe Battery
(Example: When using the FT2F1700BV2/2100BV2 with the special
charger)
1
Remove the battery cover.
2
Disconnect the battery from the T6K.
3
Balance charging cannot be done through the
transmitter, you must remove the LiFe battery to do
this charge.
&KDUJHWKHRSWLRQDO)7)%9%9
/L)HEDWWHU\ ZLWK WKH VSHFLDOFKDUJHULQDFFRU-
dance with the instruction manual supplied.
:KHQWKHEDWWHU\ZLOOQRWEHXVHGIRUDORQJWLPH
to prevent it from deteriorating we recommend
that it be kept in about the half capacity state in-
stead of fully charged. Also be careful that the bat-
tery does not enter the over-discharged state due
to self-discharge.
3HULRGLFDOO\DERXWHYHU\PRQWKVFKDUJHWKH
battery.
Over current protection
LiFe battery is removed
from transmitter.
The transmitter charging circuit is equipped with an over cur-
UHQWSURWHFWLRQFLUFXLW$,IWKHEDWWHU\LVFKDUJHGZLWKD
TXLFNFKDUJHUIRU RWKHU WKDQGLJLWDOSURSRUWLRQDO 5& VHWVLW
may not be fully charged.
Charging jack
CAUTION
Never try to recharge a dry cell battery.
The transmitter may be damaged or the battery electrolyte may
leak or the battery may break.
Insert the batteries in the correct polarity.
If the polarity is incorrect, the transmitter may be damaged.
When the transmitter is not in use, remove the batter-
ies.
If the battery electrolyte leaks, wipe off the case and contacts.
Do not use commercial AA size NiCd and NiMH batter-
ies.
Quick charging may cause the
battery contacts to overheat and
damage the battery holder.
To Next Page
