Garmin G1000 Pilot’s Guide for the Socata TBM 850
1-7
SYSTEM OVERVIEW
1.3 G1000 CONTROLS
NOTE: The Audio Panel (GMA 1347D Cabin) and AFCS controls (GMC 710) are described in the CNS & Audio
Panel and AFCS sections respectively.
The G1000 system controls are located on the PFD and MFD bezels, MFD Control Unit, AFCS Control Unit and
audio panel. The controls for the PFD and MFD are discussed within the following pages of this section.
PFD CONTROLS
Figure 1-2 PFD Controls
21 5
4
6
8
7
3
11
12
10
9
15
14
13
