Garmin G1000 Pilot’s Guide for the Socata TBM 850
190-00709-00 Rev. A5-74
FLIGHT MANAGEMENT
Figure 5-70 Approach Loading Page - Selecting the Transition
Destination Airport
Selected
Approach
Transitions Available with
Selected Approach
Approach Waypoint
Sequence
Preview of
Selected
Approach
Load Approach?
Selected Transition
Figure 5-71 Stored Flight Plan Page - Approach Inserted
Inserted Approach Header
- Approach Identifier: [approach
airport].[runway and approach type]
(e.g., KCOS-RNAV 35R
GPS LPV)
FLIGHT PLAN STORAGE
The G1000 can store up to 99 flight plans, numbered 1 through 99. The active flight plan is erased when
the G1000 is powered off or when another flight plan is activated. Details about each stored flight plan can be
viewed on the Flight Plan Catalog Page and on the Stored Flight Plan Page.
