190-01553-00 GTR 200 Installation Manual
Rev. B Page 1-1
1 GENERAL DESCRIPTION
1.1 Introduction
This manual is intended to provide mechanical and electrical information for use in the planning and
design of an installation of the GTR 200 into an aircraft. This manual is not a substitute for an approved
airframe-specific maintenance manual, installation design drawing, or complete installation data package.
Attempting to install equipment by reference to this manual alone and without first planning or designing
an installation specific to your aircraft may compromise your safety and is not recommended.
1.2 Equipment Description
CAUTION
The GTR 200 has a display that is coated with a special anti-reflective coating that is very
sensitive to waxes and abrasive cleaners. CLEANERS CONTAINING AMMONIA WILL
HARM THE ANTI-REFLECTIVE COATING. It is very important to clean the display
using a clean, lint-free cloth and an eyeglass lens cleaner that is specified as safe for anti-
reflective coatings.
CAUTION
The use of ground-based cellular telephones while aircraft are airborne is prohibited by
FCC rules. Due to potential interference with onboard systems, the use of ground-based
cell phones while the aircraft is on the ground is subject to FAA regulation 14 CFR §91.21.
FCC regulation 47 CFR §22.925 prohibits airborne operation of ground-based cellular
telephones installed in or carried aboard aircraft. Ground-based cellular telephones must
not be operated while aircraft are off the ground. When any aircraft leaves the ground, all
ground-based cellular telephones on board that aircraft must be turned off. Ground-based
cell phones that are on, even in a monitoring state, can disrupt GPS/SBAS performance.
NOTE
All screen shots used in this document are current at the time of publication. Screen shots
are intended to provide visual reference only. All information depicted in screen shots,
including software file names, versions, and part numbers, is subject to change and may
not be up to date.
Table 1-1 Available Units
Model Part Number TX Power (Watt) 8.33 KHz Spacing 25 KHz Spacing
GTR 200 011-02980-00 10 N/A Yes

Garmin GTR 200 Specifications

General

Modulation	AM
Operating Temperature	-20°C to +55°C
Channel Spacing	8.33 kHz / 25 kHz
Transmit Power	10 W
Operating Voltage	14/28 VDC systems
Frequency Range	118.000 - 136.975 MHz
