Page #28 background imageLoading...
Page #28 background image
GTR 200 Installation Manual 190-01553-00
Page 3-4 Rev. B
3.6 Post Installation Configuration and Checkout Procedures
3.6.1 System Configuration Overview
This section contains checks to ensure the system is properly installed and functioning correctly as well as
instructions for configuring the GTR 200 to the specific installation. Follow the instructions in
Section 3.6.2 through Section 3.6.7.1
in order to complete all post installation configuration and checkout
procedures.
3.6.2 Mounting, Wiring, and Power Checks
Verify that all cables are properly secured and shields are connected to the shield block of the connectors.
Check the movement of the flight and engine controls to verify there is no interference between the cabling
and control systems. Ensure that all wiring is installed as described in Section 2.7
.
Prior to powering up the unit, the wiring harness must be checked for proper connections to the aircraft
systems and other avionics equipment. Point to point continuity must be checked to expose any faults such
as shorting to ground. Any faults or discrepancies must be corrected before proceeding.
After accomplishing a continuity check, perform power and ground checks to verify proper power
distribution to the GTR 200. Any faults or discrepancies should be corrected at this time. Remove power
from the aircraft upon completion of the harness checkout.
The GTR 200 can be installed after completion of the continuity and power checks. The GTR 200 should
be installed into the rack and secured appropriately, as described in Section 3.4.2
. The GTR 200 must be
connected to the wiring harness and antenna.
3.6.3 Configuration Mode
The configuration pages shown in this section reflect main software version 2.12 or later. Some
differences in operation may be observed when comparing the information in this manual to later software
versions. Refer to Figure 3-1 to identify knobs, buttons, and softkeys used in the configuration procedures.
Configuration mode is used to configure the unit settings for each specific installation. To access
configuration mode, remove power from the unit. With the unit turned off, press and hold the SMALL
Knob and apply power by turning the Power/Volume/Squelch Knob clockwise. Release the SMALL
Knob when the display activates, the Config Mode Home page will be displayed (Figure 3-2
).
Figure 3-1 GTR 200 Front Panel
Menu
Button
Softkeys 1 (top)
and 2 (bottom)
Power/
Volume/
Squelch
Knob
Softkey
Labels
Active
Frequency
Active
Frequency
Identifier
Standby
Frequency
Standby
Frequency
Identifier
Frequency
Transfer
Key
LARGE and SMALL
Knobs
Monitor
Standby
Frequency
Micro SD
Card Slot
