190-01553-00 GTR 200 Installation Manual
Rev. B Page A-1
APPENDIX A SHIELD BLOCK CONNECTOR INSTALLATION
INSTRUCTIONS
A.1 Shield Block Installation Parts
Table 2-3 and Table A-1 list the parts needed to install a Shield Block. Parts listed in Table 2-3 are
supplied in the GTR 200 Connector Kit (011-003240-00). Parts listed in Table A-1 are to be provided by
the installer.
NOTE
In Figure A-1, “AR” denotes quantity “As Required” for the particular installation.
Table A-1 Parts not supplied for a Shield Block Installation (Figure A-1)
Figure
Ref
Description GPN or MIL spec
4
Multiple Conductor Shielded Cable (2-conductor shown in
Figure A-1
)
Parts used depend on
method chosen
5 Drain Wire Shield Termination (method optional)
Parts used depend on
method chosen
6
Braid, Flat (19-20 AWG equivalent, tinned plated copper strands
36 AWG, Circular Mil Area 1000 -1300)
Parts used depend on
method chosen
7 Floating Shield Termination (method optional)
Parts used depend on
method chosen
13 Silicon Fusion Tape -

Garmin GTR 200 Specifications

General

Modulation	AM
Operating Temperature	-20°C to +55°C
Channel Spacing	8.33 kHz / 25 kHz
Transmit Power	10 W
Operating Voltage	14/28 VDC systems
Frequency Range	118.000 - 136.975 MHz
