Garmin GTR 200 User Manual

GTR 200 Installation Manual 190-01553-00
Page 3-6 Rev. B
3.6.4.1 Default Settings
Table 3-3 lists the default values for the configuration mode settings.
Table 3-3 Configuration Default Settings
Page Setting Default Note
COM SETUP
SIDETONE 5
MIC GAIN 5
RF SQLCH 0
AUDIO SETUP INTERCOM ENABLED YES
RECEIVER OUT GAIN 100%
AUX 1 SQUELCH 30%
AUX 1 VOLUME 50%
AUX 1 MUTE (MUSIC) NO
AUX 2 SQUELCH 30%
AUX 2 VOLUME 50%
AUX 2 MUTE (MUSIC) NO
PILOT ON RIGHT SIDE NO
SOFTKEY SETUP
KEY 1 USER LIST
KEY 2 TUNE EMERGENCY
DISCRETE SETUP
DISC 1 PILOT ICS KEY
DISC 2 COPILOT ICS KEY
LIGHTING SETUP
LIGHTING SOURCE SENSOR
TIME CONSTANT 5.0/0.2
First value is photocell default;
Second value is lighting bus
default
MIN INPUT LEVEL 10%/21%
MIN BRIGHTNESS 10%/10%
MAX INPUT LEVEL 90%/86%
MAX BRIGHTNESS 100%
N/A for photocell
OFF THRESHOLD 21%
OFF HYSTERESIS 0.1%
BUTTON OFFSET 10%

Garmin GTR 200 Specifications

General

Modulation	AM
Operating Temperature	-20°C to +55°C
Channel Spacing	8.33 kHz / 25 kHz
Transmit Power	10 W
Operating Voltage	14/28 VDC systems
Frequency Range	118.000 - 136.975 MHz
