Garmin GTR 200 User Manual

190-01553-00 GTR 200 Installation Manual
Revision B Page D-5
APPENDIX D Interconnect Examples
Figure D-5 GTR 200- J2001 Connector Layout
COPILOT
HS LO
30
RESERVED
8
AUX MONO
IN 2
9
RECEIVER
AUDIO LO
29
RECEIVER
AUDIO OUT
HI
10
COPILOT
HS RIGHT
11
COPILOT
HS LEFT
12 13
AUX MONO
IN 1
32
AUX 1 LO
31
RESERVED
27
AUX 2 LO
28
COPILOT
MIC LO
34
PILOT HS
LO
33
RS232 IN
24
RESERVED
25
RESERVED
26
MUSIC LO
37
PILOT HS
LEFT
14
COPILOT
PTT
15
MUSIC IN
LEFT
19
MUSIC IN
RIGHT
18
PILOT MIC
IN
17
PILOT PTT
35
PILOT MIC
LO
36
COPILOT
MIC IN
16
PILOT HS
RIGHT
TX
INTERLOCK
OUT
45
RESERVED
7
RESERVED
6
TX
INTERLOCK
IN
DISC 1
2
RS232 OUT
23
AIRCRAFT
GROUND
20
AIRCRAFT
POWER
1
LIGHTING
BUS IN
3
SPARE
21
DISC 2
22
J2001 AS VIEWED LOOKING AT REAR OF UNIT

Garmin GTR 200 Specifications

General

Modulation	AM
Operating Temperature	-20°C to +55°C
Channel Spacing	8.33 kHz / 25 kHz
Transmit Power	10 W
Operating Voltage	14/28 VDC systems
Frequency Range	118.000 - 136.975 MHz
