GTR 200 Installation Manual 190-01553-00
Page 1-2 Rev. B
1.3 Technical Specifications
1.3.1 Physical Characteristics
1.3.2 General Specifications
Table 1-2 Physical Characteristics
Characteristics Specifications
Bezel Height 1.35 in (34.29 mm)
Bezel Width 6.25 in (158.8 mm)
Rack Height (Dimple-to-Dimple) 1.375 in (34.93 mm)
Rack Width 6.30 in (160.02 mm)
Depth Behind Panel with Connectors (Measured
from face of aircraft panel to rear of connector
backshells)
9.39 in (238.51 mm)
GTR 200 Weight (Unit Only) 1.34 lbs (0.61 kg)
GTR 200 (Installed with rack and connectors) 1.91 lbs (0.87 kg)
Table 1-3 General Specifications
Characteristics Specifications
Operating Temperature Range -20C to +55C
Humidity 95% non-condensing
Altitude Range -1,500 ft to 55,000 ft
Input Voltage Range 14/28 VDC
Current Draw* at 14 VDC
0.6 A, Typical when receiving
3.0 A, Typical when transmitting
7.50 A Maximum, 90% modulated into 3:1
VSWR and 11V power input voltage
Current Draw* at 28 VDC
0.30 A, Typical when receiving
1.40 A, Typical when transmitting
3.75 A Maximum, 90% modulated into 3:1
VSWR and 22V power input voltage
*The specified current draw is with the display backlight set to 100%

Garmin GTR 200 Specifications

General

Modulation	AM
Operating Temperature	-20°C to +55°C
Channel Spacing	8.33 kHz / 25 kHz
Transmit Power	10 W
Operating Voltage	14/28 VDC systems
Frequency Range	118.000 - 136.975 MHz
