6-8 D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL
STATUS CHAPTER 6: ACTUAL VALUES
6
6.3.13 Flex states
ACTUAL VALUES  STATUS  FLEX STATES
There are 256 FlexState
TM
bits available. The second line value indicates the state of the given FlexState bit.
6.3.14 Ethernet
ACTUAL VALUES  STATUS  ETHERNET
These values indicate the status of the first, second, and third Ethernet links.
6.3.15 Real time clock synchronizing
ACTUAL VALUES  STATUS  REAL TIME CLOCK SYNCHRONIZING
RTC SYNC SOURCE actual value is the time synchronizing source the relay is using at present. Possible sources are: Port 1
PTP Clock, Port 2 PTP Clock, Port 3 PTP Clock, IRIG-B, Other, and None, where "Other" means any less precise source (SNTP,
IEC 103, IEC 104, or DNP). An actual value displays when the relay includes the IEEE 1588 software option.
The
GRANDMASTER ID is the grandmasterIdentity code being received from the present PTP grandmaster, if any. When the
relay is not using any PTP grandmaster, this actual value is zero. The grandmasterIdentity code is specified by PTP to be
globally unique, so one can always know which clock is grandmaster in a system with multiple grandmaster-capable
clocks.
ACCURACY is the estimated maximum time error at present in the RTC, considering the quality information imbedded in the
received time signal. The value 999,999,999 indicates that the magnitude of the estimated error is one second or more, or
that the error cannot be estimated.
 FLEX STATES


PARAM 1: Off
Off
Range: On, Off


PARAM 256: Off
Off
Range: On, Off
 ETHERNET


ETHERNET PRI LINK
STATUS: Fail
Range: Fail, OK

ETHERNET SEC LINK
STATUS: Fail
Range: Fail, OK

ETHERNET TER LINK
STATUS: Fail
Range: Fail, OK
 REAL TIME CLOCK
 SYNCHRONIZING

RTC SYNC SOURCE:
None
Range: see below

GRANDMASTER ID:
0X0000000000000000
Range: any 8 octet value

ACCURACY:
999999999 ns
Range: 0 to 999,999,999 ns

PORT 1 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PORT 2 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PORT 3 PTP STATE:
No Signal
Range: Disabled, No Signal, Calibrating, Synch’d (No
Pdelay), Synchronized

PTP - IRIG-B DELTA:
500000000 ns
Range: -500,000,000 to +500,000,000 ns
