D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL A-1
D30 Line Distance Protection System
Appendix A: FlexAnalog operands
Appendices
FlexAnalog operands
This appendix outlines FlexAnalog parameters.
A.1 FlexAnalog items
A FlexAnalog parameter is an analog parameter.
FlexAnalog items are also viewable in a web browser. Enter the IP address of the UR, access the Device Information Menu
option, then the FlexAnalog Parameter Listing option. Entries displayed online depend on order code.
Table A-1: FlexAnalog data items
Address FlexAnalog name Units Description
5824 Field RTD 1 Value --- Field RTD 1 value
5825 Field RTD 2 Value --- Field RTD 2 value
5826 Field RTD 3 Value --- Field RTD 3 value
5827 Field RTD 4 Value --- Field RTD 4 value
5828 Field RTD 5 Value --- Field RTD 5 value
5829 Field RTD 6 Value --- Field RTD 6 value
5830 Field RTD 7 Value --- Field RTD 7 value
5831 Field RTD 8 Value --- Field RTD 8 value
5832 Field TDR 1 Value --- Field TDR 1 value
5834 Field TDR 2 Value --- Field TDR 2 value
5836 Field TDR 3 Value --- Field TDR 3 value
5838 Field TDR 4 Value --- Field TDR 4 value
5840 Field TDR 5 Value --- Field TDR 5 value
5842 Field TDR 6 Value --- Field TDR 6 value
5844 Field TDR 7 Value --- Field TDR 7 value
5846 Field TDR 8 Value --- Field TDR 8 value
5856 Freq Rate 1 Value Hz/s Frequency rate of change 1 actual value
5860 Freq Rate 2 Value Hz/s Frequency rate of change 2 actual value
6144 SRC 1 Ia RMS Amps Source 1 phase A current RMS
6146 SRC 1 Ib RMS Amps Source 1 phase B current RMS
6148 SRC 1 Ic RMS Amps Source 1 phase C current RMS
