Basic Service Manual
8 - 68
Section 8-5 - Replacing Cables
8-5-12-2
Removal Procedure
Steps
Corresponding Graphic
1.
Unscrew 4 screws to remove the Unity C
able Cover
Brkt.
2.
Unscrew 4 screws to remove the Unity
Cable Hide
Brkt from the console.
3.
Unlock the Cable clamp and disconnect the A
CDC
Link
Cable
To
UBE
Cable
from t
he
Unity
ACDC Ass
y.
4.
Disconnect
the
ACDC
Li
nk
Cable
To
UBE
Cable
from
the UBE.
393
395
