Chapter 11: Image Viewer
5495975-1EN Rev.9 11-10
© 2013-2017 General Electric Company. All rights reserved.
Table 11-4 Annotations/Mask tool descriptions
Tool Description
Line Places a line on the image that you may re-size, move, or angle.
Line specifications are shown in the User Measurements
annotation at the bottom right corner of the image.
Ellipse Places an ellipse (circle or oval) on the image that you may re-size,
move, or re-shape. Ellipse specifications are shown in the User
Measurements annotation at the bottom right corner of the
image.
Cobb Places a Cobb angle (two lines) on the image that you may re-size,
move, or angle. Cobb angle specifications are shown in the User
Measurements annotation at the bottom right corner of the
image.
Hide and
Show
Temporarily removes image annotations from the image. When
annotations are hidden, the button name changes to [SHOW].
Click [SHOW] to see the annotations.
Erase Deletes the selected image annotation.
Note: Deleted annotations cannot be recovered.
Erase All Deletes all image annotations.
Note: Deleted annotations cannot be recovered.
