7. Technical Specifications
PHASOR XS Operating Manual Page 93
7.3 Environmental Tests
Per Mil-Std-810F
Cold Storage -20°C for 72 hrs, 502.4
Procedure I
Cold Operation 0°C for 16 hrs, 502.4
Procedure II
Heat Storage +70°C for 48 hrs, 501.4
Procedure I
Heat Operation +50°C for 16 hrs, 501.4
Procedure II
Damp Heat / Humidity
(storage)
10 Cycles:
10hrs at +65°C down to
+30°C, 10 hrs at +30°C up to
+65°C, Transition within 2 hrs,
507.4
Temperature Shock 3 Cycles:
4 hrs at –20°C up to +70°C,
4 hrs at +70°C, Transitions
within 5 mins. 503.4
Procedure II
Vibration 514.5-5 Procedure I, Annex
C, Figure 6,
General exposure: 1hr each
axis
Shock 6 cycles each axis, 15g, 11ms
half sine, 516.5 Procedure I
Loose Cargo 514.5 Procedure II
Transit Drop
(packaged for shipment)
516.5 Procedure IV, 26 drops
IP54 / IEC529 … Dust Proof / dripping water proof as per IEC
529 specifications for IP54 classification
7.4 Phased Array Probes
Product
Code
Frequency
MHz
Element
Cable
Length
Count
Aperture Elevation Pitch
mm
2
inch
2
mm inch mm inch m ft
L8U84
2
8 8 x 9 .31 x .35
9
.35
1 .039 2 6.5
L8U96
416
8 x 9 .31 x .35
9
.35
0.5 .020 2 6.5
EUN75
532
16 x 10 .63 x .39
10
.39
0.5 .020 2 6.5
L99HK
516
16 x 10 .63 x .39
10
.39
1 .039 2 6.5
L99KO
2.25 16
16 x 13 .63 x .51
13
.51
1 .039 2 6.5
L99LQ
2.25 16
24 x 19 .94 x .75
19
.75
1.5 .059 2 6.5
L99JM
564
64 x 10 .2.5 x .39
10
.39
1 .039 2 6.5
