GE
RAFT
V
OLUSON
™ P8/V
OLUSON
™P6
DIRECTION 5775469, R
EVISION
3
DRAFT
(J
ULY
19, 2018)
B
ASIC
S
ERVICE
M
ANUAL
8-52
Section 8-18 - Replacement of
OPIO BUTTON SET
2.)
Remove 5 probe hold
ers. Refer to the figure be
low.
3.)
Lift up main keyboard as
sy.
Refer to the figure below.
Figure 8-65 Removing 5 probe holders
Figure 8-66 Lifting up main keyboard assy
413
415
