8-148 Section 8-50 - Replacement of the OPIO USB Sub PWA

Section 8-50

Replacement of the OPIO USB Sub PWA

8-50-1 Manpower

One person, 30 minutes

8-50-2 Tools

Philips screwdriver

8-50-3 Preparations

1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

2.) Remove the OPIO, covers and cables as described in 8-25-4 "Removal Procedure" on page 8-87.

8-50-4 Removal Procedure

1.) Pull 2 cables from Main Keyboard ASSY, and prepare the Sub Keyboard ASSY.

Figure 8-211 Pulling 2 cables
