GE XDP-H2 User Manual

Operation 3-3
January 2008
Initial Screen Displays Immediately upon power up, the digital display shows the following
sequence of informational screens, as the meter performs its internal
systems checks.
If the meter passes all of its internal system checks, the following data
screens appear:
Note: The padlock icon at the upper right hand corner of the above
displays indicates that the User Program is locked with
password protection.
BSeries Loader v1.03
This is a typical example of
the first initialization screen.
Boot is Flash.
Program CRC valid.
Booting from Flash
Scanning Hardware
This is a typical example of
the second initialization
screen.
Found Image Slot 1
Downloading Slot 1
Scanning Hardware
This is a typical example of
the final initialization screen.
Initializing Machine
Initializing UI
1 H2/AIR
This message appears for a
few seconds, until the sensor
begins outputting a valid gas
content signal.
mA Input Under Range
1 H2/AIR ±
The temporary absence of
valid signal triggers the Low
Low alarm, and this screen
appears.
Low Low H2 pcnt +XX.X
