Setup and Calibration 4-3
January 2008
Switching Display
Windows
If multiple XDP display windows have been configured (see Chapter
5, Advanced Programming, for instructions), the display may easily
be switched between these windows from the within the User
Program. To accomplish this, access the User Program as described
on page 3-4 and proceed as follows:
Note: As a shortcut, the display windows may be switched from
normal run mode by using the [
S] and [T] keys.
Note: Although the digital display can be switched at any time
between alternate inputs, an alarm or a recorder cannot be
switched on the fly to respond to alternate inputs. They must
be specifically configured to accept one input at a time.
Cal Opt
Disp
Use the [W] and [X] keys to
select
[Disp] and press [ENTER].
Cal Opt
Disp
All available display windows
are listed. Use the [
S] and [T]
keys to select the desired win-
dow and press
[ENTER].
1: H2/AIR pcnt
1: H2/AIR mA
Cal Opt
Disp
Press [ESC] to exit the User
Program and return to mea-
surement mode.
1 H2/AIR
After pressing [ESC] at the pre-
vious prompt, the chosen dis-
play appears.
91.52
pcnt
