Advanced Programming 5-1
January 2008
Introduction The XDP is factory-configured to provide optimum performance in
the specified application. Because many of the advanced settings
programmed into the meter during this procedure are essential for
reliable and accurate operation, the operator does not see these menu
items during routine programming of the XDP. However, in order to
address operational problems or to fine-tune the performance of the
system for a specific application, these additional programming
features are made available to authorized service personnel.
Caution!
Always consult GE Sensing before performing any of
these advanced programming functions. Improper
setup may impair the performance of the XDP system
and/or prevent it from meeting its design specifications.
Programming Levels Advanced programming of the XDP is divided into two categories,
which require passwords that are different from each other and from
the operator-level password discussed on page 3-4. All three
programming levels and the required passwords are listed below:
• Operator (Basic) Level: password = 2719
• Setup (General) Level: password = Consult Factory
• Factory (Advanced) Level: password = Consult Factory
Access the User Program as described on page 3-4 (the menu
structure that becomes available depends on which of the above three
passwords is entered at the following prompt:
To program any features of the XDP not covered in Chapters 3 or 4,
proceed to the appropriate section of this chapter.
Password
Use [W] and [X] to position the
cursor under the desired char-
acter. Then, use [
S] and [T] to
increment the value. Press
[ENTER] when done.
Enter Password
XXXX
s
Cfg Cal Opt Disp
This screen shows the initial
level of the User Program (the
main menu).
