4-6 Setup and Calibration
Setting the Display
Backlight (cont.)
Press [ESC] as many times as necessary to return to normal RUN mode,
or proceed to the appropriate section of this chapter to continue
programming the XDP.
Setting the System Fault
Alarm
The system fault alarm is not normally used for XDP applications.
However, if you do intend to use this alarm relay, the fault alarm type
may be specified by entering the User Program, as described on page
3-4, and proceeding as follows:
Note: See Appendix B, Additional Wiring Connections, for
instructions on wiring the system fault alarm.
Note: “Lock All” and “Versions” menu options also appear on the
above list.
User Backlight Timed Use [
W] and [X] to position the
cursor under the desired char-
acter. Use [
S] and [T] to enter
a time between 0 and 99 min.
When done, press
[ENTER].
Minutes
xx
s
User Backlight Press [ESC].
Off
On
Timed
User You are now back at the User
Menu.
Contrast
Backlight
Comm
Cal
Opt
Disp Use the [W] and [X] keys to
select
[Opt] and press [ENTER].
Cal
Opt
Disp Use the [S] and [T] keys to
select
[User] and press [ENTER].
User
Lock Menus
