4-10 Setup and Calibration
Setting the Zero Setpoint Enter the system analog output menu, as described on page 4-8, and
proceed as follows:
Note: The Test, Zero Trim, and Span Trim options are also available
in the above list box.
At the next prompt, enter the desired zero setpoint (the percentage of
target gas that corresponds to the lower end of the specified system
analog output range).
Either press
[ESC] until you return the User Menu or proceed to the
appropriate section to continue setting up the system analog output.
User..Aout Use the [
S] and [T] keys to
select
[Zero Setpoint], and press
[ENTER].
Aout Type
Zero Setpoint
Span Setpoint
User Aout Zero-Set Use [
W] and [X] to position the
cursor under the desired char-
acter. Then, use [
S] and [T] to
increment the value. Press
[ENTER] when done.
Zero Set
xxxx.xxxxx
s
User..Aout You are now back at the sys-
tem analog output setup menu.
Aout Type
Zero Setpoint
Span Setpoint
