Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
18
4.6.2 TRIGger:EDGe:SLOPe
4.6.3 TRIGger:EDGe:LEVel
4.7 TRIGger:PULSe
Command List
⚫ TRIGger:PULSe:SOURce
⚫ TRIGger:PULSe:POLarity
⚫ TRIGger:PULSe:WHEN
⚫ TRIGger:PULSe:WIDth
⚫ TRIGger:PULSe:LEVel
4.7.1 TRIGger:PULSe:SOURce
4.7.2 TRIGger:PULSe:POLarity
Command
:TRIGger:EDGe:SLOPe <slope>
:TRIGger:EDGe:SLOPe?
Description
Set or query the type of edge trigger.
Parameters
:<slope> ::= < RISIng| FALLing | EITHer >
State
▷RISIng: rising edge
▷FALLing: falling edge
▷EITHer: rising or falling edge
Return
The query returns RISIng, FALLing, EITHer
Example
:TRIGger:EDGe:SLOPe RISIng /*Set the edge type to rising edge*/
:TRIGger:EDGe:SLOPe? /*The query returns RISIng*/
Command
:TRIGger:EDGe:LEVel <level>
:TRIGger:EDGe:LEVel?
Description
Set or query the trigger level when the edge triggers.
Parameters
:<level> ::= trigger level ( unit is V)
Return
The query returns the trigger level value in scientific notation.
Example
:TRIGger:EDGe:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:EDGe:LEVel? /*The query returns 1.600e-1*/
Command
:TRIGger:PULSe:SOURce <source>
:TRIGger:PULSe:SOURce?
Description
Set or query the trigger source of the pulse width trigger.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:PULSe:SOURce CHANnel1 /*set trigger source to CH1*/
:TRIGger:PULSe:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:PULSe:POLarity <polarity>
:TRIGger:PULSe:POLarity?
