Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
29
4.14.4 TRIGger:UART:ALEVel
4.14.5 TRIGger:UART:DATA
4.14.6 TRIGger:UART:WIDTh
4.14.7 TRIGger:UART:PARIty
:TRIGger:UART:BAUd?
Description
Set or query the baud rate triggered by the UART. The default unit is bps.
Parameters
:<baud> ::=<110|300|600|1200|2400|4800|9600|14400|19200|38400|57600|115200|230
400|380400|460400|921600|USER>
Return
The query returns an integer or USER.
Example
:TRIGger:UART:BAUd 4800 /*Set the baud rate to 4800*/
:TRIGger:UART:BAUd? /*he query returns 4800*/
Command
:TRIGger:UART:ALEVel <level>
:TRIGger:UART:ALEVel?
Description
Set or query the trigger level when the UART triggers.
Parameters
:<level> ::= trigger level value (in V)
Return
The query returns the trigger level in scientific notation.
Example
:TRIGger:UART:ALEVel 0.16 /*Set trigger level 160mV*/
:TRIGger:UART:ALEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:UART:DATA <data>
:TRIGger:UART:DATA?
Description
Set or query the data value when the UART trigger condition is data.
Parameters
:<data> ::= (0-- (2
n-1
-1) )
State
n is the current data width, and the value range is 5, 6, 7, or 8.
Return
The query returns an integer.
Example
:TRIGger:UART:DATA 10 /*Set the data value to 10*/
:TRIGger:UART:DATA? /*The query returns 10*/
Command
:TRIGger:UART:WIDTh <value>
:TRIGger:UART:WIDTh?
Description
Sets or queries the data bit width when the UART trigger condition is data.
Parameters
:<value> ::= <5,6,7,8>
Return
The query returns 5, 6, 7, or 8.
Example
:TRIGger:UART:WIDTh 5 /*Set the data bit width to 5*/
:TRIGger:UART:WIDTh? /*The query returns 5*/
Command
:TRIGger:UART:PARIty <parity>
:TRIGger:UART:PARIty?
Description
Set or query the verification mode when the UART trigger condition is an error
frame or a verification error.
Parameters
:<parity> ::= < NONE| ODD| EVEN>
Return
The query returns EVEN, ODD, or NONE.
Example
:TRIGger:UART:PARIty EVEN /*Set the parity method to even parity*/
:TRIGger:UART:PARIty? /*The query returns EVEN*/
