Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
31
4.15.4 TRIGger:CAN:CONdition
4.15.5 TRIGger:CAN:ID
4.15.6 TRIGger:CAN:DLC
4.15.7 TRIGger:CAN:DATA
4.15.8 TRIGger:CAN:ALEVel
Command
:TRIGger:CAN:CONdition <condition>
:TRIGger:CAN:CONdition?
Description
Set or query the trigger conditions for CAN trigger
Parameters
:<condition> ::= < FRAM_STARE | FRAM_REMO_ID | FRAM_DATA_ID |
REMO/DATA_ID | DATA_ID/DATA | FRAM_REE | FRAM_OVERLOAD | ERR_ALL |
ACK_ERR >
Return
Query returns FRAM_STARE | FRAM_REMO_ID | FRAM_DATA_ID
|REMO/DATA_ID | DATA_ID/DATA | FRAM_REMO_ID_EXT |FRAM_DATA_ID_EXT
| REMO/DATA_ID_EXT |DATA_ID/DATA_EXT | FRAM_REE | FRAM_OVERLOAD |
ERR_ALL | ACK_ERR
Example
:TRIGger:CAN:CONdition FRAM_STARE /*Set FRAM_STARE*/
:TRIGger:CAN:CONdition? /*The query returns FRAM_STARE*/
Command
:TRIGger:CAN:ID <id>
:TRIGger:CAN:ID?
Description
Set or query the IDENTIFIER triggered by CAN
Parameters
:<id> ::= 0 -- 28
Return
The query returns an integer
Example
:TRIGger:CAN:ID 25 /*Set IDENTIFIER to 25*/
:TRIGger:CAN:ID? /*The query returns 25*/
Command
:TRIGger:CAN:DLC <dlc>
:TRIGger:CAN:DLC?
Description
Set or query the data length code of CAN trigger
Parameters
:<dlc> ::= 4 digits
Return
The query returns an integer
Example
:TRIGger:CAN:DLC 10 /*Set the data length code to 10*/
:TRIGger:CAN:DLC? /*The query returns 10*/
Command
:TRIGger:CAN:DATA <index> <data>
:TRIGger:CAN:DATA? <index>
Description
Set or query CAN trigger data value
Parameters
:<data> ::= 8 digits
:<index> ::= data index 0-3
Return
The query returns an integer
Example
:TRIGger:CAN:DATA 2,10 /*Set the data with index 2 to 10*/
:TRIGger:CAN:DATA? 2 /*The query returns 10*/
Command
:TRIGger:CAN:ALEVel <level>
:TRIGger:CAN:ALEVel?
