Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
52
11.1 MASK:EANBle
11.2 MASK:SOURce
11.3 MASK:MDISplay
11.4 MASK:Output
Command
:MASK:EANBle <bool>
:MASK:EANBle?
Description
Turn the pass / fail test function on or off, or query the status of the pass / fail test
function.
Parameters
:<bool> ::= {{1 | ON} | {0 | OFF}
Return
The query returns ON,OFF
Example
:MASK:EANBle ON /*Turn on the pass / fail test function*/
:MASK:EANBle? /*The query returns ON*/
Command
:MASK:SOURce <source>
:MASK:SOURce?
Description
Set or query the measurement source of the pass / fail test.
Parameters
:<source> ::= < CHANnel1|CHANnel2|MATH>
Return
The query returns CHANnel1, CHANnel2, MATH
Example
:MASK:SOURce CHANnel1 /*Set the measurement source of the pass / fail test to
CH1*/
:MASK:SOURce? /*The query returns CHANnel1*/
Command
:MASK:MDISplay <bool>
:MASK:MDISplay?
Description
When the pass / fail test is turned on, turn statistics on or off, or query the status of
the statistics.
Parameters
:<bool> ::= {{1 | ON} | {0 | OFF}
Return
The query returns ON,OFF.
Example
:MASK:MDISplay ON /*Open statistics*/
:MASK:MDISplay?/*The query returns ON*/
Command
:MASK:OUTPut <bool>
:MASK:OUTPut?
Description
Turn output on or off, or query output stop status.
Parameters
:<bool> ::= {{1 | ON} | {0 | OFF}
State
▷On: When a failed waveform is detected, the oscilloscope will stop the test and enter
the "STOP" state. At this time, the screen keeps displaying the measurement result
(if the display is turned on), and the rear panel [Trigger Out] (if enabled) outputs only
one pulse.
▷Off: Even if a failed waveform is detected, the oscilloscope will continue the test,
and the test results on the screen are continuously updated. The [Trigger Out] on the
rear panel will output a pulse each time a failed waveform is detected.
Return
The query returns ON,OFF
Example
:MASK:OUTPut ON /*Stop the output*/
:MASK:OUTPut? /*The query returns ON*/
