Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
50
⚫ MEASure:GATE:AY
⚫ MEASUre:GATE:BY
10.1 MEASure:ENABle
10.2 MEASure:SOURce
10.3 MEASure:ADISplay
10.4 MEASure: CHANnel<n>:ITEM
Command
:MEASure:ENABle <bool>
:MEASure:ENABle?
Description
Set or query the measurement function status
Parameters
:<bool> ::= {{1 | ON} | {0 | OFF}
Return
The query returns ON,OFF
Example
:MEASure:ENABle ON /*turn on measurement function*/
:MEASure:ENABle? /*Query returns ON*/
Command
:MEASure:SOURce <source>
:MEASure:SOURce?
Description
Set or query the source of the current measurement parameters.
Parameters
:<source> ::= < CHANnel1|CHANnel2|CHANnel3|CHANnel4| MATH>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4,MATH
Example
:MEASure:SOURce CHANnel1 /*Set parameter measurement source to CH1*/
:MEASure:SOURce? /*Query returns CHANnel1*/
Command
:MEASure:ADISplay <bool>
:MEASure:ADISplay?
Description
Turn all measurements on or off, or query the current status of all measurements.
Parameters
:<bool> ::= {{1 | ON} | {0 | OFF}
Return
The query returns ON,OFF.
Example
:MEASure:ADISplay ON /*Turn on all measurements*/
:MEASure:ADISplay? /*Query returns ON*/
Command
:MEASure: CHANnel<n>:ITEM <type>
:MEASure: CHANnel<n>:ITEM?
Description
Query the measurement result of the specified parameter
Parameters
:<n>::= {1 | 2 | 3 | 4}
:<type>::=<
MAX,VMIN,VPP,VTOP,VBASe,VAMP,VAVG,VRMS,OVERshoot,PREShoot,MARea,MP
ARea,PERiod,FREQuency,RTIMe,FTIMe,PWIDth,NWIDth,PDUTy,NDUTy,RDELay,FDE
Lay,RPHase,FPHase,TVMAX,TVMIN,PSLEWrate,NSLEWrate,VUPper,
VMID,VLOWer,VARIance,PVRMS,PPULses,NPULses,PEDGes,NEDGes>
Return
The query returns
Example
:MEASure:CHANnel1:ITEM? VPP /*The query returns VPP 3.600e-01 */
