Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
28
4.13.6 TRIGger:UNDER_Am:BLEVel
4.14 TRIGger:UART
Command List
⚫ TRIGger:UART:SOURce
⚫ TRIGger:UART:CONdition
⚫ TRIGger:UART:BAUd
⚫ TRIGger:UART:ALEVel
⚫ TRIGger:UART:DATA
⚫ TRIGger:UART:WIDTh
⚫ TRIGger:UART:PARIty
4.14.1 TRIGger:UART:SOURce
4.14.2 TRIGger:UART:CONdition
4.14.3 TRIGger:UART:BAUd
Return
The query returns the upper trigger level in scientific notation.
Example
:TRIGger:UNDER_Am:ALEVel 0.16 /*Set the trigger level upper limit to 160mV*/
:TRIGger:UNDER_Am:ALEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:UNDER_Am:BLEVel <level>
:TRIGger:UNDER_Am:BLEVel?
Description
Set or query the lower limit of the trigger level when the runt pulse is triggered.
Parameters
:<level> ::=trigger level lower limit value (in V)
Return
The query returns the lower trigger level in scientific notation.
Example
:TRIGger:UNDER_Am:BLEVel 0.16 /*Set the trigger level lower limit to 160mV*/
:TRIGger:UNDER_Am:BLEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:UART:SOURce <source>
:TRIGger:UART:SOURce?
Description
Set or query the trigger conditions for UART trigger.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:UART:SOURce CHANnel1 /*Set the trigger source to CH1*/
:TRIGger:UART:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:UART:CONdition <condition>
:TRIGger:UART:CONdition?
Description
Set or query the trigger conditions for UART trigger.
Parameters
:<condition> ::= < START| STOP| READ_DATA| PARITY_ERR| COM_ERR>
Return
The query returns START | STOP | READ_DATA | PARITY_ERR | COM_ERR
Example
:TRIGger:UART:CONdition START /*Set the trigger condition to START*/
:TRIGger:UART:CONdition? /*The query returns START*/
Command
:TRIGger:UART:BAUd <baud>
