Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
30
4.15 TRIGger:CAN
Command List
⚫ TRIGger:CAN:SOURce
⚫ TRIGger:CAN:IDLe
⚫ TRIGger:CAN:BAUd
⚫ TRIGger:CAN:CONdition
⚫ TRIGger:CAN:ID
⚫ TRIGger:CAN:DLC
⚫ TRIGger:CAN:DATA
⚫ TRIGger:CAN:ALEVel
4.15.1 TRIGger:CAN:SOURce
4.15.2 TRIGger:CAN:IDLe
4.15.3 TRIGger:CAN:BAUd
Command
:TRIGger:CAN:SOURce <source>
:TRIGger:CAN:SOURce?
Description
Set or query the trigger source of CAN trigger.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:CAN:SOURce CHANnel1 /*Set the trigger source to CH1*/
:TRIGger:CAN:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:CAN:IDLe <idle>
:TRIGger:CAN:IDLe?
Description
Set or query the idle level triggered by CAN
Parameters
:<idle> ::= <LOW | HIGH>
Return
The query returns LOW, HIGH
Example
:TRIGger:CAN:IDLe LOW /*Set idle low level*/
:TRIGger:CAN:IDLe? /*The query returns LOW*/
Command
:TRIGger:CAN:BAUd <baud>
:TRIGger:CAN:BAUd?
Description
Set or query the baud rate triggered by CAN. The default unit is bps.
Parameters
:<baud> ::=<10000|20000|33300|50000|62500|83300|100000|125000|250000|500000|8
00000|1000000|USER>
Return
The query returns an integer
Example
:TRIGger:CAN:BAUd 4800 /*Set the baud rate to 4800*/
:TRIGger:CAN:BAUd? /*The query returns 4800*/
