Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
23
4.9.5 TRIGger:TV:STANdard
4.9.6 TRIGger:VIDeo:LEVel
4.10 TRIGger:TIMeout
Command List
⚫ TRIGger:TIMeout:SOURce
⚫ TRIGger:TIMeout:LEVel
⚫ TRIGger:TIMeout:WIDth
⚫ TRIGger:TIMeout:POLarity
4.10.1 TRIGger:TIMeout:SOURce
4.10.2 TRIGger:TIMeout:LEVel
Command
:TRIGger:TV:STANdard <standard>
:TRIGger:TV:STANdard?
Description
Set or query the video standard of the video
Parameters
:<standard> ::= < NTSC | PAL >
Return
The query returns NTSC, PAL
Example
:TRIGger:TV:STANdard NTSC /*Select NTSC video standard*/
:TRIGger:TV:STANdard? /*The query returns NTSC*/
Command
:TRIGger:VIDeo:LEVel <level>
:TRIGger:VIDeo:LEVel?
Description
Set orquery the trigger level when the video is triggered.
Parameters
:<level> ::= trigger level value (in V)
Return
The query returns the trigger level in scientific notation.
Example
:TRIGger:VIDeo:LEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:VIDeo:LEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:TIMeout:SOURce <source>
:TRIGger:TIMeout:SOURce?
Description
Sets or queries the trigger source of the timeout trigger.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:TIMeout:SOURce CHANnel1 /*Set trigger source to CH1*/
:TRIGger:TIMeout:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:TIMeout:LEVel <level>
:TRIGger:TIMeout:LEVel?
Description
Set or query the trigger level when the timeout triggers.
Parameters
:<level> ::= trigger level value (in V)
Return
Returns the trigger level value in scientific notation
Example
:TRIGger:TIMeout:LEVel 0.16 /*Set trigger level 160mV*/
:TRIGger:TIMeout:LEVel? /*The query returns 1.600000e-01*/
