Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
21
4.8.4 TRIGger:SLOPe:WIDth
4.8.5 TRIGger:SLOPe:ALEVel
4.8.6 TRIGger:SLOPe:BLEVel
4.9 TRIGger:TV
Command List
⚫ TRIGger:TV:SOURce
⚫ TRIGger:TV:POLarity
⚫ TRIGger:TV:MODE
⚫ TRIGger:TV:LINE
⚫ TRIGger:TV:STANdard
⚫ TRIGger:VIDeo:LEVel
Return
The query returns EQUAl, NEQUal, GRAt, LESS
Example
:TRIGger:SLOPe:WHEN NEQUal /*Set trigger condition to NEQUal*/
:TRIGger:SLOPe:WHEN? /*The query returns NEQUal*/
Command
:TRIGger:SLOPe:WIDth <value>
:TRIGger:SLOPe:WIDth?
Description
Set or query the trigger condition of the slope trigger.
Parameters
:<value> ::=trigger condition value (in second)
Return
The query returns the time value in scientific notation.
Example
:TRIGger:SLOPe:WIDth 0.000003 /*Set the width value to 3μs*/
:TRIGger:SLOPe:WIDth? /*The query returns 3.000000e-06*/
Command
:TRIGger:SLOPe:ALEVel <level>
:TRIGger:SLOPe:ALEVel?
Description
Set or query the upper limit of the trigger level when the slope triggers.
Parameters
:<level> ::=trigger level upper limit value (in V)
Return
The query returns the upper limit value of the trigger level in scientific notation.
Example
:TRIGger:SLOPe:ALEVel 0.16 /*Set the trigger level to 160mV*/
:TRIGger:SLOPe:ALEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:SLOPe:BLEVel <level>
:TRIGger:SLOPe:BLEVel?
Description
Set or query the lower limit of the trigger level when the slope triggers.
Parameters
:<level> ::=trigger level lower limit value (in V)
Return
The query returns the lower limit value of the trigger level in scientific notation.
Example
:TRIGger:SLOPe:BLEVel 0.16 /*Set the trigger level to lower limit*/
:TRIGger:SLOPe:BLEVel? /*The query returns 1.600000e-01*/
