Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
32
4.16 TRIGger:LIN
Command List
⚫ TRIGger:LIN:SOURce
⚫ TRIGger:LIN:IDLe
⚫ TRIGger:LIN:BAUd
⚫ TRIGger:LIN:CONdition
⚫ TRIGger:LIN:ID
⚫ TRIGger:LIN:DATA
⚫ TRIGger:LIN:ALEVel
4.16.1 TRIGger:LIN:SOURce
4.16.2 TRIGger:LIN:IDLe
4.16.3 TRIGger:LIN:BAUd
Description
Set or query the trigger level during CAN trigger
Parameters
:<level> ::= trigger level value (in V)
Return
Returns the trigger level value in scientific notation
Example
:TRIGger:CAN:ALEVel 0.16 /*Set trigger level 160mV*/
:TRIGger:CAN:ALEVel? TRIGger:CAN:ALEVel?
Command
:TRIGger:LIN:SOURce <source>
:TRIGger:LIN:SOURce?
Description
Set or query the trigger source of the LIN trigger.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:LIN:SOURce CHANnel1 /*Set the trigger source to CH1*/
:TRIGger:LIN:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:LIN:IDLe <idle>
:TRIGger:LIN:IDLe?
Description
Set or query the idle level triggered by LIN
Parameters
:<idle> ::= <LOW | HIGH>
Return
The query returns LOW, HIGH
Example
:TRIGger:LIN:IDLe LOW /*Set idle low level*/
:TRIGger:LIN:IDLe? /*The query returns LOW*/
Command
:TRIGger:LIN:BAUd <baud>
:TRIGger:LIN:BAUd?
Description
Set or query the baud rate triggered by LIN. The default unit is bps.
Parameters
:<baud> ::=<110|300|600|1200|2400|4800|9600|14400|19200|38400|57600|115200|230
