Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
35
4.17.5 TRIGger:IIC:DATA
4.17.6 TRIGger:IIC:ALEVel
4.17.7 TRIGger:IIC:BLEVel
4.18 TRIGger:SPI
Command List
⚫ TRIGger:SPI:SDA:SOURce
⚫ TRIGger:SPI:SCL:SOURce
⚫ TRIGger:SPI:SCK
⚫ TRIGger:SPI:WIDth
⚫ TRIGger:SPI:DATA
Description
Set or query the address value when the IIC trigger condition is an address or
address data.
Parameters
:<addr> ::= 8 digits
Return
The query returns an integer.
Example
:TRIGger:IIC:ADDer 20 /*Set the address value to 20*/
:TRIGger:IIC:ADDer? /*The query returns START 20*/
Command
:TRIGger:IIC:DATA <index> <data>
:TRIGger:IIC:DATA? <index>
Description
Set or query the data value when the IIC trigger condition is data or address
data.
Parameters
:<data> ::= 8 digits
:<index> ::= data index 0-8
Return
The query returns an integer.
Example
:TRIGger:IIC:DATA 2,10 /* Set the data with index 2 to 10*/
:TRIGger:IIC:DATA? 2 /* The query returns 10*/
Command
:TRIGger:IIC:ALEVel <level>
:TRIGger:IIC:ALEVel?
Description
Set or query the trigger level of the clock line when I2C triggers.
Parameters
:<level> ::= trigger level value (in V)
Return
The query returns the trigger level in scientific notation.
Example
:TRIGger:IIC:ALEVel 0.16 /* Set the trigger level to 160mV */
:TRIGger:IIC:ALEVel? /* The query returns 1.600000e-01*/
Command
:TRIGger:IIC:BLEVel <level>
:TRIGger:IIC:BLEVel?
Description
Set or query the trigger level of the data line when I2C triggers.
Parameters
:<level> ::= trigger level value (in V)
Return
The query returns the trigger level in scientific notation.
Example
:TRIGger:IIC:BLEVel 0.16 /* Set the trigger level to 160mV */
:TRIGger:IIC:BLEVel? /* The query returns 1.600000e-01*/
