Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
33
4.16.4 TRIGger:LIN:CONdition
4.16.5 TRIGger:LIN:ID
4.16.6 TRIGger:LIN:DATA
4.16.7 TRIGger:LIN:ALEVel
4.17 TRIGger:IIC
Command List
400|380400|460400|921600|USER>
Return
The query returns an integer
Example
:TRIGger:LIN:BAUd 4800 /*set the baud rate is 4800*/
:TRIGger:LIN:BAUd? /*The query returns 4800*/
Command
:TRIGger:LIN:CONdition <condition>
:TRIGger:LIN:CONdition?
Description
LIN trigger conditions set trigger or queries
Parameters
:<condition> ::= <
INTERVAL_FIELD|SYNC_FIELD|ID_FIELD|DATA|IDENTIFIER|ID_DATA >
Return
The query returns INTERVAL_FIELD | SYNC_FIELD | ID_FIELD | DATA |
IDENTIFIER | ID_DATA
Example
:TRIGger:LIN:CONdition DATA /*set INTERVAL_END*/
:TRIGger:LIN:CONdition? /*The query returns INTERVAL_END*/
Command
:TRIGger:LIN:ID <id>
:TRIGger:LIN:ID?
Description
Set or query LIN triggered identifier
Parameters
:<id> ::= 6 digits
Return
The query returns an integer
Example
:TRIGger:LIN:ID 25 /*Set identifier to 25*/
:TRIGger:LIN:ID? /*The query returns 25*/
Command
:TRIGger:LIN:DATA <index> <data>
:TRIGger:LIN:DATA? <index>
Description
Set or query data values triggered by LIN.
Parameters
:<data> ::= 8 digits
:<index> ::= data index 0-3
Return
The query returns an integer
Example
:TRIGger:LIN:DATA 2 ,10 /*Set the data with index 2 to 10*/
:TRIGger:LIN:DATA? 2 /*The query returns 10*/
Command
:TRIGger:LIN:ALEVel <level>
:TRIGger:LIN:ALEVel?
Description
Set or query the trigger level during LIN trigger
Parameters
:<level> ::= trigger level value ( in V)
Return
Returns the trigger level value in scientific notation
Example
:TRIGger:LIN:ALEVel 0.16 /*Set trigger level 160mV*/
:TRIGger:LIN:ALEVel? /*The query returns 1.600000e-01*/
