Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
24
4.10.3 TRIGger:TIMeout:WIDth
4.10.4 TRIGger:TIMeout:POLarity
4.11 TRIGger:WINDOw
Command List
⚫ TRIGger:WINDOw:SOURce
⚫ TRIGger:WINDOw:ALEVel
⚫ TRIGger:WINDOw:BLEVel
4.11.1 TRIGger:WINDOw:SOURce
4.11.2 TRIGger:WINDOw:ALEVel
Command
:TRIGger:TIMeout:WIDth <value>
:TRIGger:TIMeout:WIDth?
Description
Sets or queries the timeout period triggered by the timeout.
Parameters
:<value> ::=trigger timeout value (range: 8ns-10s)
Return
The query returns the timeout value in scientific notation.
Example
:TRIGger:TIMeout:WIDth 0.000003 /*Set the timeout time to 3μs*/
:TRIGger:TIMeout:WIDth? /*The query returns 3.000000e-06*/
Command
:TRIGger:TIMeout:POLarity <polarity>
:TRIGger:TIMeout:POLarity?
Description
Sets or queries the polarity of edge triggered by the timeout.
Parameters
:<polarity> ::= < POSItive | NEGAtive>
State
▷POSItive: Start the timing by the trigger level on the rising edge of the input
signal.
▷NEGAtive: Starts timing with the trigger level on the falling edge of the input
signal.
Return
The query returns POSItive, NEGAtive.
Example
:TRIGger:TIMeout:POLarity POSItive /*Set to positive polarity of the trigger*/
:TRIGger:TIMeout:POLarity? /*The query returns POSItive*/
Command
:TRIGger:WINDOw:SOURce <source>
:TRIGger:WINDOw:SOURce?
Description
Set or query the trigger source triggered by the window.
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4.
Example
:TRIGger:WINDOw:SOURce CHANnel1 /*Set trigger source to CH1*/
:TRIGger:WINDOw:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:WINDOw:ALEVel <level>
:TRIGger:WINDOw:ALEVel?
Description
Set or query the upper limit of the trigger level when the super window is sent.
Parameters
:<level> ::=trigger level upper limit value (in V)
Return
The query returns the upper trigger level in scientific notation.
