Hantek DSO2000 Series Programmer's Manual

SCPI Programmers Manual
25
4.11.3 TRIGger:WINDOw:BLEVel
4.12 TRIGger:INTERVAl
Command List
⚫ TRIGger:INTERVAl:SOURce
⚫ TRIGger:INTERVAl:SLOp
⚫ TRIGger:INTERVAl:WHEN
⚫ TRIGger:INTERVAl:TIME
⚫ TRIGger:INTERVAl:ALEVel
4.12.1 TRIGger:INTERVAl:SOURce
4.12.2 TRIGger:INTERVAl:SLOp
Example
:TRIGger:WINDOw:ALEVel 0.16 /*Set the trigger level upper limit to 160mV*/
:TRIGger:WINDOw:ALEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:WINDOw:BLEVel <level>
:TRIGger:WINDOw:BLEVel?
Description
Set or query the lower limit of the trigger level when the amplitude trigger is
triggered.
Parameters
:<level> ::=trigger level lower limit value (in V)
Return
The query returns the lower trigger level in scientific notation.
Example
:TRIGger:WINDOw:BLEVel 0.16 /*Set the trigger level lower limit to 160mV*/
:TRIGger:WINDOw:BLEVel? /*The query returns 1.600000e-01*/
Command
:TRIGger:INTERVAl:SOURce <source>
:TRIGger:INTERVAl:SOURce?
Description
Set or query the trigger source for interval trigger
Parameters
:<source> ::= < CHANnel1 | CHANnel2 | CHANnel3 | CHANnel4>
State
Triggered when the interval between two consecutive rising edges (or falling
edges) meets the set time condition (<,>, =,! =)
Return
The query returns CHANnel1, CHANnel2, CHANnel3, CHANnel4
Example
:TRIGger:INTERVAl:SOURce CHANnel1 /*Set the trigger source to CH1*/
:TRIGger:INTERVAl:SOURce? /*The query returns CHANnel1*/
Command
:TRIGger:INTERVAl:SLOp <slope>
:TRIGger:INTERVAl:SLOp?
Description
Set or query the type of edge triggered by the interval
Parameters
:<slope> ::= < RISIng| FALLing>
State
▷RISIng: rising edge trigger
▷FALLing: falling edge trigger
▷DOUBle: Double edge trigger
Return
The query returns RISIng, FALLing, DOUBle
Example
:TRIGger:INTERVAl:SLOp RISIng /Set the edge type to rising edge*/
:TRIGger:INTERVAl:SLOp? /*The query returns POSItive*/
