Hardi SMARTCOM ISOBUS UT SW A.2.2 Series User Manual

3 - Description
38
2. 1. 1. 18 Extra sensor 1F Readout from extra sensor 1 frequency
2. 1. 1. 19 Extra sensor 2F Readout from extra sensor 2 frequency
2. 1. 1. 20 Extra sensor 3A Readout from extra sensor 3 analogue
2. 1. 1. 21 Extra sensor 4A Readout from extra sensor 4 analogue
2. 1. 1. 22 Voltmeter Displays system voltage. Useful when fault finding
2. 1. 1. 23 Agitation Agitation valve opening
2. 1. 1. 24 RinseTank content RinseTank calculated content
2. 1. 1. 25 Slant angle Headland assist angle sensor
2. 1. 1. 26 Boom height Headland assist height sensor
2. 1. 1. 27 Air pressure Displays compressor air pressure if sensor is fitted
2. 1. 1. 28 Reserved R R
2. 1. 1. 29 Reserved R R
2. 1. 1. 30 Reserved R R
2. 1. 1. 31 Reserved R R
2. 1. 1. 32 Reserved R R
2. 1. 1. 33 Nozzle size flow at 3 bar Calculated nozzle flow at 3 bar
2. 1. 1. 34 Reserved R R
2. 1. 1. 35 Hitch Angle
2. 1. 1. 36 Linkage Angle
2. 1. 1. 37 PF bus + Voltage on PrimeFlow databus +
2. 1. 1. 38 PF bus - Voltage on PrimeFlow databus -
2. 1. 2 Show upper right
2. 1. 2. 01 Prog volume rate litre/ha Shows Programmed volume rate Application rate litre per hectare
2. 1. 2. 02 Boom flow Boom flow per minute sprayed out through the boom
2. 1. 2. 03 Time Actual time
2. 1. 2. 04 Work rate ha/hour Rate shown in hectare per hour or acre per hour
2. 1. 2. 05 Actual volume rate litre/ha Actual rate in litre per hectare or gallon per acre
2. 1. 2. 06 Tank contents Main tank contents
2. 1. 2. 07 Speed Driving speed
2. 1. 2. 08 Volume sprayed Readouts for Volume sprayed in currently active register
2. 1. 2. 09 Area sprayed Readouts for Area sprayed in currently active register
2. 1. 2. 10 Active boom size Active boom size including end nozzle
2. 1. 2. 11 Pressure Displays spray pressure if sensor is fitted
2. 1. 2. 12 Fan speed Displays Twin fan speed if sensor is fitted
2. 1. 2. 13 Wind Speed Displays wind speed if sensor is fitted
2. 1. 2. 14 Pendulum lock status Displays reading of pendulum lock sensor if fitted
2. 1. 2. 15 Pendulum unlock status Displays reading of pendulum unlock sensor if fitted
2. 1. 2. 16 Dynamic centre position Displays Dynamic centre position sensor if fitted
2. 1. 2. 17 Spray pump rev Displays revolutions if sensor is fitted
2. 1. 2. 18 Extra sensor 1F Readout from extra sensor 1 frequency
2. 1. 2. 19 Extra sensor 2F Readout from extra sensor 2 frequency
2. 1. 2. 20 Extra sensor 3A Readout from extra sensor 3 analogue
2. 1. 2. 21 Extra sensor 4A Readout from extra sensor 4 analogue
2. 1. 2. 22 Voltmeter Displays system voltage. Useful when fault finding
2. 1. 2. 23 Agitation Agitation valve opening
2. 1. 2. 24 RinseTank content RinseTank calculated content
2. 1. 2. 25 Slant angle Headland assist angle sensor
2. 1. 2. 26 Boom height Headland assist height sensor
2. 1. 2. 27 Air pressure Displays compressor air pressure if sensor is fitted
2. 1. 2. 28 Reserved R R
2. 1. 2. 29 Reserved R R
2. 1. 2. 30 Reserved R R
2. 1. 2. 31 Reserved R R
Menu Number Menu Name Help Text in Display
