Page 64
CDi DriveCore Series Operation Manual
Device Presets
Loading Device Presets
To load a device preset from the front panel:
1� From the Home screen, press the MENU button.
2� Select the "Configure Amplifier" option from the menu using the ENCODER.
3� Select the "Load Preset" option.
4� Use the ENCODER to navigate presets using the on-screen "PREV" and "NEXT"
buttons. As each preset is selected, the preset number, name, and configuration will be
displayed on-screen.
5� Once the desired preset has been selected, use the ENCODER to select "LOAD".
For information on loading device presets in Audio Architect, see "Main CDi DriveCore
Control Panel" on page 34
.
Figure 77: Loading a device preset
