Page 67
CDi DriveCore Series Operation Manual
System Settings
Amp Gain Mode
The Amp Gain setting sets how much gain will be applied to the signal within the amplifier
(from input to output) and can be set from the Amp Gain Mode screen.
To edit the Amp Gain setting:
1� From the Home screen, press the MENU button.
2� Select the "System Settings" option from the menu using the ENCODER.
3� Select the "Amp Gain" option from the menu.
4� Press the ENCODER to edit the Amp Gain setting.
5� Turn the ENCODER to select the desired Amp Gain setting.
6� When done, press the ENCODER to make the selection then select "Done" at the
bottom of the screen.
Available options:
• Amp Gain (+37dB, +34dB, +26dB)
Sets how much gain will be applied to the signal within the amplifier (from input to output).
Power Modes
The APD and ACD power modes allow the CDi DriveCore amplifiers to conserve power
consumption during periods of inactivity. The APD and ACD features are enabled by default
from the factory.
To edit power mode settings:
1� From the Home screen, press the MENU button.
2� Select the "System Settings" option from the menu using the ENCODER.
3� Select the "Power Modes" option from the menu.
4� Turn and press the ENCODER to select the desired settings.
5� When done, select "Done" at the bottom of the screen.
Available options:
• APD Enable
Checking this checkbox enables the APD feature.
• ACD Enable
Checking this checkbox enables the ACD feature.
See "Amplier Information" on page 35 for information on editing power mode settings in Audio Architect.
See "Power Saving Modes" on page 71 for additional information on the APD and ACD features.
Figure 80: Amp Gain Mode screen
Figure 81: Power Modes screen
