CDi DriveCore Series Operation Manual
AC Power Draw & Thermal Dissipation
AC Power Draw & Thermal Dissipation
CDi DriveCore 2|300 / 2|300BL
Pink noise 12dB crest factor, bandwidth limited 22Hz to 22kHz.
Typical line impedance used.
Data based on all channels driven.
This product was safety certified to ±10% of the voltage range 100–240V~. This information is for reference only.
CDi DriveCore 2|300 / 2|300BL – Dual
120 VAC / 60Hz 230 VAC / 50Hz
Condition Load
Line
current
(amps)
Power Dissipated as Heat Line
current
(amps)
Power Dissipated as Heat
watts BTU kcal/hr watts BTU kcal/hr
At Idle Awake
N/A 0.6 73 251 63 0.4 102 347 88
1/8 Power
Pink Noise
Typical of program
material just at clip
2Ω 1. 1 91 310 78 0.7 119 405 102
4Ω 1. 4 97 331 83 0.8 118 403 102
8Ω 1. 4 86 295 74 0.8 108 368 93
70V 1. 3 83 282 71 0.8 102 350 88
100V 1. 3 80 272 69 0.8 102 347 87
1/3 Power
Pink Noise
Typical of program
material at
extreme clip
2Ω 1. 9 123 419 106 1. 1 140 479 121
4Ω 2.8 138 471 119 1. 5 150 512 129
8Ω 2.6 116 397 100 1. 4 125 428 108
70V 2.5 110 377 95 1. 4 115 391 99
100V 2.5 99 337 85 1. 3 381 381 96
CDi DriveCore 2|300 / 2|300BL – Bridged
120 VAC / 60Hz 230 VAC / 50Hz
Condition Load
Line
current
(amps)
Power Dissipated as Heat Line
current
(amps)
Power Dissipated as Heat
watts BTU kcal/hr watts BTU kcal/hr
At Idle Awake
N/A 0.6 73 250 63 0.4 102 348 88
1/8 Power
Pink Noise
Typical of program
material just at clip
4Ω 1. 4 92 313 79 0.8 112 382 96
8Ω 1. 3 84 286 72 0.8 107 365 92
70V 1. 3 79 271 68 0.8 102 349 88
100V 1. 3 79 271 68 0.8 101 345 87
1/3 Power
Pink Noise
Typical of program
material at
extreme clip
4Ω 2.8 127 432 109 1. 5 138 471 119
8Ω 2.7 112 381 96 1. 4 123 419 106
70V 2.5 101 344 87 1. 3 111 378 95
100V 2.5 99 338 85 1. 3 111 378 95
