User Manual of DS-7200-ST Series DVR
96
4. Select OK to save settings and exit the current menu.
To configure the video input mode settings:
1. Click Menu > Settings > Camera to enter the Camera Settings menu.
2. Click the Advanced tab to enter the Advanced Camera Settings menu, as shown in Figure 3.
Figure 3. Video Output Mode Settings Menu
3. Select the Input Mode to Standard, Gentle or Bright.
4. Select OK to save settings and exit the current menu.
Image Settings
Image settings such as the brightness, contrast, saturation and hue can also be adjusted in the Camera Management
menu.
To adjust image settings:
1. Click Menu > Settings > Camera to enter the Camera Settings menu, shown in Figure 3.
2. Click the Advanced tab to enter the Advanced Camera Settings menu, as shown in Figure1.
Select channel for image settings in Camera.
3. Click the Set button next to the Image Settings label.
4. Adjust the image settings, as shown in Figure 3. Brightness, contrast, saturation and hue can be
adjusted in the menu. The adjustments of image settings will affect the live images and the
recorded images.
