User Manual of DS-7200-ST Series DVR
97
Figure 3. Image Settings
Privacy Mask Settings
You may setup privacy mask to mask off sensitive or private areas in the field of view of a camera.
To configure privacy mask:
1. Click Menu > Settings > Camera to enter the Camera Settings menu.
2. Click the Advanced tab to enter the Advanced Camera Settings menu, as shown in Figure 4.
Select channel for privacy mask settings in Camera.
Figure 4. Advanced Camera Settings Menu
3. Check the Mask checkbox to enable feature.
4. Click the Area Settings button to enter Area Settings menu.
5. Set mask area, as shown in Figure 5. Up to 4 areas can be configured.
Figure 5. Setting Mask Area
6. Select Exit to save settings and exit the Mask Area Settings interface.
