MAINTENANCE
7-20
B. ENGINE
1
Engine Oil Level --- check daily
IMPORTANT: For most accurate readings, check the oil
level every day before starting the machine.
Be sure the machine is on a level surface.
1. Remove dipstick (1). Wipe oil off with a clean cloth. Rein-
sert dipstick (1).
2. Remove dipstick (1) again. Read level. Oil level must be
between the circle marks.
3. If necessary, add oil via oil filler cap (2).
Be sure to use only recommended oil (see Recommended
Engine Oil Chart).
NOTE: Checking the oil level immediately after shut down will
result in inaccurate readings.
Be sure to allow the oil to settle for at least 10 minutes
before checking.
2
1
Max.
Min.
M1U1-07-044
M178-07-011
2
1
M1U1-07-093
1
ZX120-3, 180-3 Class
ZX200-3, 270-3, 330-3 Class
To Next Page
