Honeywell IPC5000 User Manual

- 21 -
Table 2.7.2 Instrument input range code and range
Instrument input range
Input type
Input
range
code
ºC ºF
Measurement accuracy:
± 0.1% of span typical(± 1 digit for display)
0~10V DCV1 +/-0.1%FS
0~5V DCV2 +/-0.1%FS
DC
Voltage
1~5V DCV3
Programmable range
-19999 ~ 20000
(Decimal point position is
variable)
+/-0.1%FS
0~20mA MA1 +/-0.1%FS
DC
Current
4~20mA MA2
Programmable range
-19999 ~ 20000
(Decimal point position is
variable)
+/-0.1%FS
Pt1 -200.0~500.0 -328.0~932.0 +/-0.1%FS
Pt2 -200.0~200.0 -328.0~392.0 +/-0.1%FS
Pt3 -100.0~150.0 -148.0~302.0 +/-0.1%FS
Pt4 -50.0~200.0 -58.0~392.0 +/-0.1%FS
Pt5 -40.0~60.0 -40.0~140.0 +/-0.2%FS
Pt6 0.0~100.0 32.0~212.0 +/-0.2%FS
Pt7 0.0~300.0 32.0~572.0 +/-0.1%FS
RTD
Pt100
(JIS/IEC)
Pt8 0.0~500.0 32.0~932.0 +/-0.1%FS
JPt1 -200.0~500.0 -328.0~932.0 +/-0.1%FS
JPt2 -200.0~200.0 -328.0~392.0 +/-0.1%FS
JPt3 -100.0~150.0 -148.0~302.0 +/-0.1%FS
JPt4 -50.0~200.0 -58.0~392.0 +/-0.1%FS
JPt5 -40.0~60.0 -40.0~140.0 +/-0.2%FS
JPt6 0.0~100.0 32.0~212.0 +/-0.2%FS
JPt7 0.0~300.0 32.0~572.0 +/-0.1%FS
RTD
JPt100
(JIS)
JPt8 0.0~500.0 32.0~932.0 +/-0.1%FS
* FS : Full Scale
NEXT
