3.17 SYSTEM SET screen
Fig. 3.17.1 SYSTEM SET screen
(NOTE)
To change the system data except LANGUAGE, set the controller operation mode to the
STOP status first.
(1) Control Mode selection button
z Select whether control operation is synchronous or asynchronous. (Default = Asynchronous)
z ASYNCH. : Asynchronous mode that both channels operate independently.
That is, RUN and STOP can be operation for each channel.
z SYNCH. : Synchronous mode that both channels operate dependently.
That is, RUN and STOP runs with each channel.
(2) SP tracking
If the SP tracking is ON, the controller enters into the condition that program control changes to fix
control when the last segment is completed. The next operation after completion of program
operation is determined by the JC condition of the last segment and the SP tracking ON/OFF as
shown in the Figure 3.17.2.
When the SP tracking function is enabled, the target setting value (SP) at the program end
becomes the target setting value of the fix control. The PV event runs as the event set by the fix
control and the time event does not work. SP tracking operation is enabled only when the SP
tracking is on and the JC value at the last segment of the program is set to 2.
(1)
(5)
(2)
(3)
(4)
(6)
03-02.WED
SYSTEM SET
EXIT
12.59.00
ASYNCH. SYNCH.
OFF ON
TIME UNIT
HR.MIN MIN.SEC
TIME SLOPE
RAMP UNIT
LANGUAGE
ENG KOR CHN
SYS SET
TROUBLE
INITIAL
NET SET
< DO Adjust to CH >
CH1: 1 to
6
CH2: 7 to 12
SP TRACKING
CONTROL MODE
