3.10 EVENT SET
z IPC5000 has 12 events in case of synchronous mode and each 6 events for channel 1 and
2 in case of asynchronous mode. And multiple events can be arranged to the same digital
output.
z Event TYPE
Signal No Signal name Description Used range Set Position
00
EVENT OFF Event output OFF
Only Program
control
User set area
01
EVENT ON Event output ON
Only Program
control
User set area
02~17
TIME EVENT
(For detail, refer
to User Manual)
ON Delay and Cutback
Only Program
control
User set area
21~40
PV EVENT
OFF/ON according to a changing of
PV, SP, DEV, and MV
Program and
Fix control
User set area
STOP
RUN
READY
END
HOLD
ADV
WAIT
Auto Tune
Manual
FIX
DOWN
41~60
MODE EVENT
UP
Program and
Fix control
Maker set area
61~80
ALARM Event Alarm event output
Program and
Fix control
Maker set area
(NOTE 1)
Mode and Alarm Event can assign the digital output number directly in the event set screen. And
Event OFF/ON, Time Event or PV Event can assign digital output number in the Fix Set screen or
Segment set screen of program. The digital number that Mode or Alarm event already is assigned
can be not assigned to Time Event and PV Event. Refer to the user manual for Fix and Segment
set screen.
(NOTE 2)
User set area : User area who use some Equipment or System and it is a input part to set at
Fix or program.
Maker set area : Maker area who install or make a trial run of some Equipment or System
and it is a input part to set at Mode or Alarm event.
